Aluminum Bulb Angle

Description

Aluminum Bulb Angle is an aerospace shapes are used in the manufacture and repair of commercial and military aircraft. Material produced and stocked by Aircraft Extrusion Co in 2024, 7075 and 6061 aircraft alloys and are supplied with full test reports to aircraft and FAA specification of AMS-QQ-A-200/3, AMS-QQ-A-200/11 and AMS-QQ-A-200/8. Aircraft Extrusion Co is AS9100 Rev C and ISO9001:2008 certified company.

Part Number	A	B	T1	T2	R	R1	R2	R3	R4	R5	Deg.
Clear Filter
AND10135-1001	1.000	0.688	0.050	0.050	0.075	0.050	0.075	0.075	0.010	0.010	90. 00
AND10135-1002	1.000	0.750	0.063	0.063	0.095	0.063	0.095	0.095	0.010	0.010	90. 00
AND10135-1003	1.000	0.750	0.078	0.078	0.117	0.078	0.117	0.117	0.010	0.010	90. 00
AND10135-1004	1.000	0.875	0.078	0.078	0.117	0.078	0.117	0.117	0.010	0.010	90. 00
AND10135-1005	1.000	1.000	0.078	0.078	0.117	0.078	0.117	0.117	0.010	0.010	90. 00
TMS60-10057	0.900	0.940	0.065	0.065	0.090	0.016	0.090	0.090	0.016	0.016	90. 00
TMS60-10111	0.750	0.625	0.051	0.051	0.125	0.016	0.062	0.062	0.016	0.016	90. 00
TMS60-10128	0.709	0.590	0.063	0.063	0.062	0.016	0.078	0.078	0.016	0.016	90. 00
TMS60-10257	1.000	0.875	0.063	0.063	0.095	0.010	0.095	0.095	0.010	0.010	90. 00
TMS60-10286	1.000	1.030	0.100	0.160	0.120	0.016	0.120	0.100	0.016	0.016	90. 00
TMS60-10356	1.000	0.750	0.050	0.050	0.125	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-10489	1.750	1.000	0.080	0.100	0.156	0.100	0.156	0.156	0.010	0.010	90. 00
TMS60-10577	1.250	0.875	0.172	0.125	0.125	0.032	0.125	0.172	0.032	0.032	90. 00
TMS60-10705	0.875	0.813	0.063	0.063	0.125	0.063	0.094	0.094	0.016	0.016	90. 00
TMS60-10759	0.875	0.750	0.050	0.050	0.062	0.016	0.125	0.078	0.016	0.016	90. 00
TMS60-11068	1.000	1.500	0.050	0.050	0.050	0.016	0.095	0.095	0.100	0.016	90. 00
TMS60-11092	1.115	0.653	0.041	0.045	0.125	0.022	0.118	0.093	0.016	0.022	90. 00
TMS60-11113	0.800	0.900	0.050	0.050	0.085	0.016	0.085	0.085	0.016	0.016	90. 00
TMS60-11142	1.500	1.000	0.100	0.070	0.150	0.016	0.150	0.150	0.016	0.016	90. 00
TMS60-11175	1.000	1.000	0.062	0.062	0.094	0.016	0.125	0.078	0.016	0.016	90. 00
TMS60-11416	1.000	1.250	0.063	0.063	0.093	0.031	0.093	0.093	0.031	0.031	90. 00
TMS60-11481	0.875	1.000	0.078	0.078	0.117	0.078	0.117	0.117	0.010	0.010	90. 00
TMS60-11760	1.500	1.000	0.070	0.070	0.187	0.016	0.187	0.187	0.016	0.016	90. 00
TMS60-11778	0.810	0.900	0.040	0.040	0.075	0.016	0.075	0.075	0.016	0.016	90. 00
TMS60-11789	0.625	0.830	0.131	0.106	0.125	0.016	0.090	0.125	0.016	0.016	90. 00
TMS60-11826	1.500	1.170	0.080	0.120	0.120	0.120	0.120	0.120	0.016	0.016	90. 00
TMS60-11827	1.000	0.875	0.068	0.068	0.125	0.030	0.156	0.086	0.030	0.030	90. 00
AND10135-1201	1.250	0.875	0.078	0.078	0.117	0.078	0.117	0.117	0.010	0.010	90. 00
TMS60-12129	1.000	0.800	0.062	0.062	0.062	0.016	0.062	0.090	0.016	0.016	90. 00
TMS60-12247	1.020	1.500	0.094	0.110	0.090	0.016	0.090	0.117	0.016	0.016	90. 00
TMS60-12326	1.250	1.060	0.078	0.078	0.117	0.016	0.117	0.117	0.016	0.016	90. 00
TMS60-12353	0.562	1.250	0.102	0.094	0.094	0.094	0.094	0.094	0.032	0.032	90. 00
TMS60-12392	0.800	0.800	0.050	0.050	0.062	0.016	0.062	0.060	0.016	0.016	90. 00
TMS60-12470	0.897	0.500	0.072	0.072	0.090	0.016	0.090	0.097	0.016	0.016	90. 00
TMS60-12579	0.500	1.000	0.050	0.050	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-12661	0.875	0.625	0.062	0.062	0.078	0.016	0.062	0.062	0.016	0.016	90. 00
TMS60-12817	0.750	0.750	0.082	0.082	0.094	0.016	0.062	0.094	0.016	0.016	90. 00
TMS60-12941	0.500	0.750	0.040	0.040	0.062	0.016	0.062	0.062	0.016	0.016	90. 00
TMS60-12949	0.750	0.750	0.040	0.062	0.090	0.016	0.090	0.062	0.016	0.016	90. 00
TMS60-13283	0.750	1.000	0.050	0.050	0.125	0.016	0.125	0.062	0.016	0.016	90. 00
TMS60-133	0.500	0.812	0.051	0.051	0.062	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-13359	0.709	0.591	0.064	0.064	0.087	0.012	0.069	0.069	0.012	0.012	90. 00
TMS60-13494	1.100	0.750	0.058	0.090	0.060	0.016	0.060	0.094	0.016	0.016	90. 00
TMS60-13736	0.600	1.850	0.060	0.060	0.070	0.020	0.020	0.060	0.020	0.020	90. 00
TMS60-13969	1.100	1.010	0.070	0.120	0.125	0.016	0.125	0.070	0.016	0.016	90. 00
AND10135-1401	1.500	0.875	0.078	0.078	0.117	0.078	0.117	0.117	0.010	0.010	90. 00
TMS60-14469	0.690	0.625	0.050	0.050	0.070	0.016	0.050	0.070	0.016	0.016	90. 00
TMS60-1447	1.000	0.875	0.078	0.078	0.125	0.010	0.156	0.086	0.010	0.010	90. 00
TMS60-14499	1.000	0.780	0.102	0.102	0.060	0.016	0.060	0.120	0.016	0.016	90. 00
TMS60-14621	1.260	0.787	0.079	0.079	0.079	0.020	0.079	0.118	0.020	0.020	90. 00
TMS60-14745	1.380	1.120	0.140	0.140	0.156	0.090	0.156	0.156	0.031	0.031	90. 00
TMS60-14794	0.787	0.630	0.047	0.047	0.047	0.012	0.047	0.069	0.012	0.012	90. 00
TMS60-14895	0.875	0.500	0.062	0.062	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-14930	1.312	0.750	0.094	0.094	0.141	0.031	0.141	0.141	0.031	0.031	90. 00
TMS60-15003	2.000	1.150	0.100	0.200	0.125	0.016	0.125	0.125	0.016	0.016	90. 00
AND10135-1501	1.625	0.875	0.094	0.094	0.117	0.094	0.117	0.117	0.010	0.010	90. 00
TMS60-15025	0.593	0.593	0.040	0.040	0.047	0.016	0.047	0.047	0.016	0.016	90. 00
TMS60-15041	1.000	1.600	0.063	0.063	0.130	0.016	0.090	0.045	0.016	0.016	90. 00
TMS60-15102	1.969	1.260	0.126	0.126	0.126	0.032	0.126	0.177	0.032	0.032	90. 00
TMS60-15103	2.480	1.575	0.157	0.157	0.157	0.039	0.157	0.236	0.039	0.039	90. 00
TMS60-15149	1.250	1.250	0.078	0.078	0.117	0.039	0.117	0.150	0.032	0.039	90. 00
TMS60-1521	0.875	0.750	0.062	0.062	0.094	0.031	0.094	0.094	0.010	0.031	90. 00
TMS60-15213	1.500	1.188	0.078	0.078	0.117	0.039	0.117	0.150	0.032	0.039	90. 00
TMS60-15229	0.750	0.870	0.070	0.070	0.070	0.010	0.031	0.070	0.010	0.010	90. 00
TMS60-15338	0.875	0.562	0.060	0.060	0.062	0.031	0.094	0.094	0.031	0.031	90. 00
TMS60-15381	1.100	1.470	0.070	0.110	0.125	0.016	0.125	0.070	0.016	0.016	90. 00
TMS60-15432	1.100	1.200	0.070	0.110	0.125	0.016	0.125	0.070	0.016	0.016	90. 00
TMS60-15580	0.787	0.630	0.063	0.063	0.063	0.031	0.063	0.099	0.031	0.031	90. 00
TMS60-15581	1.969	1.260	0.118	0.118	0.118	0.030	0.118	0.177	0.030	0.030	90. 00
TMS60-15649	0.750	0.530	0.040	0.040	0.060	0.015	0.120	0.040	0.015	0.015	90. 00
TMS60-15877	1.000	0.840	0.080	0.085	0.125	0.031	0.125	0.125	0.031	0.031	90. 00
TMS60-15879	1.000	1.070	0.050	0.050	0.060	0.016	0.060	0.063	0.016	0.016	90. 00
TMS60-15971	1.125	1.750	0.100	0.175	0.156	0.156	0.120	0.120	0.031	0.031	90. 00
AND10135-1601	1.750	1.125	0.094	0.094	0.117	0.094	0.117	0.117	0.010	0.010	90. 00
AND10135-1602	1.750	1.250	0.109	0.109	0.136	0.109	0.136	0.136	0.010	0.010	90. 00
TMS60-16026	1.208	0.620	0.060	0.079	0.065	0.025	0.125	0.086	0.025	0.025	90. 00
AND10135-1603	1.750	1.250	0.125	0.125	0.156	0.125	0.156	0.156	0.010	0.010	90. 00
TMS60-1613	1.500	0.750	0.064	0.100	0.125	0.100	0.125	0.125	0.031	0.031	90. 00
TMS60-1615	0.560	0.750	0.051	0.051	0.062	0.031	0.062	0.062	0.031	0.031	90. 00
TMS60-16273	0.669	0.630	0.039	0.039	0.079	0.016	0.039	0.063	0.016	0.016	90. 00
TMS60-16334	0.866	0.669	0.071	0.071	0.118	0.016	0.079	0.089	0.016	0.016	90. 00
TMS60-16475	0.688	0.750	0.071	0.071	0.094	0.016	0.063	0.094	0.016	0.016	90. 00
TMS60-16614	1.125	0.980	0.100	0.125	0.125	0.031	0.125	0.115	0.031	0.031	90. 00
TMS60-16660	0.750	0.950	0.150	0.093	0.125	0.062	0.125	0.156	0.031	0.031	90. 00
TMS60-16694	1.094	0.625	0.078	0.078	0.125	0.016	0.125	0.117	0.016	0.016	90. 00
TMS60-16760	0.750	0.900	0.140	0.081	0.125	0.062	0.125	0.140	0.032	0.016	90. 00
TMS60-16763	1.100	1.160	0.070	0.120	0.125	0.016	0.125	0.070	0.016	0.016	90. 00
TMS60-16788	1.000	0.931	0.125	0.150	0.125	0.031	0.125	0.140	0.031	0.031	90. 00
TMS60-16975	1.200	1.000	0.045	0.045	0.060	0.010	0.060	0.060	0.010	0.010	90. 00
TMS60-16996	1.000	1.000	0.070	0.070	0.117	0.016	0.117	0.117	0.016	0.016	90. 00
TMS60-17044	1.200	1.100	0.070	0.110	0.125	0.031	0.125	0.100	0.031	0.031	90. 00
TMS60-17166	0.625	0.810	0.050	0.050	0.090	0.016	0.090	0.080	0.016	0.016	90. 00
TMS60-17327	0.400	1.850	0.060	0.060	0.070	0.020	0.020	0.060	0.020	0.020	90. 00
TMS60-17387	1.000	0.820	0.078	0.078	0.125	0.031	0.125	0.086	0.031	0.031	90. 00
TMS60-17698	1.375	1.500	0.125	0.125	0.125	0.016	0.188	0.188	0.016	0.016	90. 00
TMS60-17841	0.984	0.787	0.079	0.079	0.079	0.020	0.079	0.118	0.020	0.020	90. 00
TMS60-18482	0.875	0.750	0.062	0.062	0.062	0.016	0.125	0.078	0.016	0.016	90. 00
TMS60-18502	1.250	1.000	0.090	0.160	0.125	0.031	0.125	0.100	0.031	0.031	90. 00
TMS60-1877	1.000	1.000	0.060	0.080	0.125	0.016	0.125	0.062	0.016	0.016	90. 00
TMS60-19090	1.100	1.470	0.070	0.120	0.125	0.016	0.125	0.070	0.016	0.016	90. 00
TMS60-19185	0.750	0.750	0.050	0.050	0.075	0.010	0.075	0.125	0.010	0.010	90. 00
TMS60-1931	1.250	0.900	0.075	0.140	0.062	0.062	0.062	0.094	0.031	0.031	90. 00
TMS60-1954	1.500	1.250	0.094	0.170	0.125	0.016	0.094	0.078	0.016	0.016	90. 00
TMS60-19556	1.000	0.810	0.090	0.090	0.094	0.016	0.094	0.078	0.016	0.016	90. 00
TMS60-19794	1.125	0.813	0.094	0.094	0.117	0.094	0.117	0.117	0.016	0.016	90. 00
TMS60-2004	0.910	2.250	0.063	0.063	0.125	0.016	0.250	0.080	0.016	0.016	90. 00
TMS60-20237	1.125	1.080	0.100	0.125	0.125	0.031	0.125	0.115	0.031	0.031	90. 00
TMS60-20259	1.500	0.875	0.070	0.100	0.125	0.031	0.125	0.125	0.031	0.031	90. 00
TMS60-20292	0.630	0.551	0.039	0.039	0.079	0.012	0.039	0.063	0.012	0.012	90. 00
TMS60-20398	0.500	0.700	0.045	0.045	0.060	0.016	0.060	0.060	0.016	0.016	90. 00
TMS60-2046	1.000	0.880	0.062	0.062	0.094	0.031	0.125	0.078	0.030	0.031	90. 00
TMS60-2089	0.749	1.250	0.070	0.070	0.094	0.016	0.040	0.095	0.016	0.016	90. 00
TMS60-2115	0.500	0.875	0.090	0.090	0.060	0.015	0.100	0.100	0.015	0.015	90. 00
TMS60-21367	1.000	0.900	0.058	0.112	0.062	0.062	0.062	0.075	0.031	0.031	90. 00
TMS60-21412	1.250	1.000	0.094	0.094	0.094	0.094	0.125	0.125	0.094	0.094	90. 00
TMS60-21991	1.000	1.100	0.110	0.125	0.125	0.031	0.125	0.140	0.031	0.031	90. 00
TMS60-22157	3.250	4.000	0.250	0.188	0.250	0.040	0.250	0.280	0.040	0.040	90. 00
TMS60-22624	0.800	1.000	0.040	0.040	0.020	0.016	0.032	0.063	0.016	0.016	90. 00
TMS60-22905	0.930	0.750	0.060	0.120	0.060	0.031	0.085	0.085	0.031	0.031	90. 00
TMS60-22925	1.380	1.250	0.220	0.150	0.180	0.031	0.180	0.230	0.031	0.031	90. 00
TMS60-2294	0.405	0.840	0.062	0.062	0.075	0.031	0.075	0.075	0.016	0.031	90. 00
TMS60-23356	1.750	1.100	0.110	0.140	0.136	0.140	0.136	0.136	0.016	0.016	90. 00
TMS60-23472	1.187	0.937	0.080	0.070	0.125	0.010	0.125	0.109	0.010	0.010	90. 00
TMS60-23683	0.800	1.200	0.078	0.078	0.100	0.031	0.100	0.100	0.031	0.031	90. 00
TMS60-23976	1.188	0.813	0.083	0.083	0.063	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-24363	1.875	1.750	0.250	0.187	0.125	0.016	0.219	0.219	0.016	0.016	90. 00
TMS60-24551	0.688	0.625	0.050	0.050	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-2459	1.250	1.600	0.150	0.250	0.120	0.030	0.120	0.155	0.030	0.030	90. 00
TMS60-24591	1.250	0.880	0.125	0.125	0.125	0.030	0.125	0.117	0.030	0.030	90. 00
TMS60-24785	1.380	1.050	0.125	0.125	0.120	0.016	0.120	0.153	0.016	0.016	90. 00
TMS60-2481	1.000	0.938	0.064	0.064	0.064	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-2497	1.000	1.000	0.093	0.093	0.125	0.046	0.125	0.125	0.031	0.046	90. 00
TMS60-25209	1.000	1.125	0.050	0.050	0.125	0.016	0.095	0.095	0.016	0.016	90. 00
TMS60-25283	1.188	1.125	0.188	0.093	0.125	0.047	0.125	0.156	0.032	0.047	90. 00
TMS60-2562	0.900	1.000	0.065	0.065	0.090	0.016	0.090	0.090	0.016	0.016	90. 00
TMS60-25621	0.688	0.750	0.080	0.080	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-2565	1.250	1.250	0.064	0.064	0.090	0.090	0.090	0.090	0.031	0.031	90. 00
TMS60-25684	1.250	1.250	0.094	0.094	0.117	0.094	0.117	0.117	0.010	0.010	90. 00
TMS60-2581	1.500	1.125	0.100	0.100	0.125	0.050	0.125	0.125	0.030	0.050	90. 00
TMS60-25855	0.875	0.563	0.062	0.062	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-26088	1.000	0.380	0.050	0.050	0.032	0.025	0.032	0.060	0.032	0.025	90. 00
TMS60-26287	1.000	0.890	0.125	0.150	0.150	0.031	0.125	0.140	0.031	0.031	90. 00
TMS60-26306	0.984	1.024	0.118	0.118	0.118	0.016	0.118	0.118	0.016	0.016	90. 00
TMS60-2653	1.062	0.750	0.080	0.080	0.125	0.031	0.125	0.117	0.031	0.031	90. 00
TMS60-26833	1.150	0.850	0.060	0.075	0.090	0.031	0.090	0.110	0.031	0.031	90. 00
TMS60-26975	1.375	0.750	0.050	0.050	0.093	0.010	0.093	0.093	0.010	0.010	90. 00
TMS60-27064	1.250	1.250	0.094	0.094	0.125	0.016	0.141	0.141	0.016	0.016	90. 00
TMS60-27534	0.750	0.750	0.040	0.040	0.090	0.016	0.090	0.062	0.016	0.016	90. 00
TMS60-27645	0.625	1.000	0.051	0.051	0.075	0.051	0.075	0.075	0.010	0.010	90. 00
TMS60-2803	1.000	1.000	0.071	0.071	0.125	0.016	0.110	0.110	0.016	0.016	90. 00
TMS60-28635	0.688	0.750	0.080	0.080	0.090	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-28673	2.500	2.600	0.090	0.075	0.125	0.016	0.125	0.156	0.016	0.016	90. 00
TMS60-29316	1.000	0.875	0.078	0.078	0.120	0.016	0.160	0.090	0.016	0.016	90. 00
TMS60-29353	1.000	1.000	0.100	0.100	0.100	0.031	0.100	0.120	0.031	0.031	90. 00
TMS60-29441	1.000	1.250	0.078	0.078	0.090	0.031	0.120	0.120	0.031	0.031	90. 00
TMS60-31007	0.750	0.750	0.060	0.060	0.060	0.015	0.094	0.094	0.015	0.015	90. 00
TMS60-3168	0.750	1.000	0.078	0.078	0.125	0.030	0.125	0.125	0.030	0.030	90. 00
TMS60-31724	0.675	0.625	0.051	0.051	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-31868	1.000	1.000	0.070	0.200	0.117	0.117	0.117	0.117	0.031	0.031	90. 00
TMS60-31985	1.500	1.170	0.080	0.080	0.120	0.080	0.120	0.120	0.031	0.031	90. 00
TMS60-3200	0.900	1.000	0.050	0.050	0.090	0.016	0.075	0.075	0.016	0.016	90. 00
TMS60-32863	0.812	0.500	0.052	0.052	0.062	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-33043	1.000	0.688	0.064	0.064	0.064	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-33693	1.550	2.040	0.120	0.110	0.188	0.031	0.188	0.188	0.031	0.031	90. 00
TMS60-33737	1.250	1.625	0.100	0.062	0.125	0.030	0.125	0.093	0.030	0.030	90. 00
TMS60-338	0.750	0.750	0.063	0.063	0.095	0.063	0.095	0.095	0.010	0.010	90. 00
TMS60-33913	1.250	0.875	0.078	0.078	0.117	0.078	0.117	0.117	0.016	0.016	90. 00
TMS60-34161	0.984	0.984	0.079	0.079	0.079	0.016	0.079	0.098	0.016	0.016	90. 00
TMS60-34241	0.709	0.591	0.064	0.064	0.087	0.016	0.069	0.069	0.016	0.016	90. 00
TMS60-34338	0.984	0.787	0.098	0.079	0.098	0.016	0.098	0.069	0.016	0.016	90. 00
TMS60-34428	1.000	0.875	0.062	0.062	0.094	0.016	0.094	0.078	0.016	0.016	90. 00
TMS60-34429	1.000	0.880	0.062	0.062	0.094	0.031	0.125	0.078	0.040	0.031	90. 00
TMS60-34499	0.709	0.630	0.039	0.039	0.079	0.008	0.039	0.063	0.008	0.008	90. 00
TMS60-34509	1.260	0.787	0.079	0.079	0.079	0.019	0.079	0.118	0.019	0.019	90. 00
TMS60-34518	1.000	0.938	0.064	0.064	0.064	0.010	0.064	0.094	0.010	0.010	90. 00
TMS60-34569	0.630	0.630	0.063	0.063	0.063	0.016	0.063	0.098	0.016	0.016	90. 00
TMS60-34585	0.797	0.700	0.062	0.062	0.078	0.016	0.078	0.078	0.016	0.016	90. 00
TMS60-34691	1.000	1.125	0.079	0.079	0.118	0.016	0.118	0.138	0.016	0.016	90. 00
TMS60-34788	0.800	0.793	0.063	0.063	0.095	0.010	0.117	0.117	0.063	0.010	90. 00
TMS60-34811	1.000	1.181	0.063	0.063	0.110	0.016	0.110	0.114	0.016	0.016	90. 00
TMS60-34814	1.000	1.181	0.039	0.039	0.079	0.016	0.079	0.081	0.016	0.016	90. 00
TMS60-35119	1.000	1.181	0.098	0.098	0.098	0.016	0.118	0.158	0.016	0.016	90. 00
TMS60-35502	0.750	1.250	0.063	0.063	0.090	0.016	0.120	0.090	0.016	0.016	90. 00
TMS60-35523	1.000	0.750	0.063	0.063	0.095	0.063	0.095	0.095	0.016	0.016	90. 00
TMS60-3553	1.700	1.200	0.130	0.130	0.188	0.032	0.094	0.156	0.032	0.032	90. 00
TMS60-35635	0.750	0.750	0.063	0.063	0.095	0.010	0.095	0.095	0.010	0.010	90. 00
TMS60-35897	1.266	0.656	0.085	0.085	0.125	0.016	0.125	0.125	0.016	0.016	90. 00
TMS60-35909	1.750	1.000	0.093	0.093	0.125	0.016	0.750	0.250	0.016	0.016	90. 00
TMS60-36052	0.500	0.625	0.040	0.040	0.060	0.040	0.060	0.060	0.015	0.015	90. 00
TMS60-36080	0.900	0.900	0.070	0.070	0.125	0.031	0.125	0.219	0.031	0.031	90. 00
TMS60-36888	1.000	0.820	0.063	0.063	0.080	0.020	0.080	0.100	0.020	0.020	90. 00
TMS60-3700	1.063	0.940	0.094	0.094	0.094	0.016	0.094	0.188	0.063	0.016	90. 00
TMS60-3843	2.250	1.250	0.100	0.125	0.190	0.125	0.190	0.190	0.016	0.016	90. 00
TMS60-3855	1.000	0.750	0.051	0.062	0.094	0.031	0.078	0.078	0.031	0.031	90. 00
TMS60-3856	1.312	1.250	0.070	0.085	0.125	0.062	0.094	0.094	0.031	0.031	90. 00
TMS60-3857	0.880	1.125	0.062	0.062	0.040	0.031	0.062	0.062	0.031	0.031	90. 00
TMS60-3886	1.500	1.000	0.080	0.100	0.156	0.100	0.156	0.156	0.031	0.031	90. 00
TMS60-3960	1.375	1.000	0.125	0.125	0.156	0.125	0.156	0.156	0.016	0.016	90. 00
TMS60-3975	1.000	0.750	0.050	0.050	0.062	0.010	0.062	0.075	0.010	0.010	90. 00
AND10135-0401	0.500	0.500	0.040	0.040	0.060	0.040	0.060	0.060	0.010	0.010	90. 00
AND10135-0402	0.500	0.625	0.040	0.040	0.060	0.040	0.060	0.060	0.010	0.010	90. 00
TMS60-4060	1.380	0.750	0.064	0.080	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-414	1.047	1.156	0.125	0.094	0.125	0.047	0.016	0.125	0.016	0.047	90. 00
TMS60-4269	0.625	1.000	0.062	0.062	0.075	0.016	0.075	0.075	0.016	0.016	90. 00
TMS60-4407	0.880	0.880	0.060	0.060	0.120	0.016	0.120	0.094	0.016	0.016	90. 00
TMS60-4499	2.120	1.250	0.062	0.062	0.120	0.031	0.120	0.120	0.031	0.031	90. 00
TMS60-4695	0.950	2.050	0.080	0.070	0.047	0.031	0.094	0.094	0.031	0.031	90. 00
TMS60-4716	0.797	0.797	0.062	0.062	0.078	0.016	0.078	0.078	0.016	0.016	90. 00
TMS60-4739	0.750	0.500	0.040	0.040	0.062	0.016	0.032	0.062	0.016	0.016	90. 00
TMS60-4758	0.880	0.750	0.063	0.063	0.080	0.031	0.080	0.080	0.031	0.031	90. 00
TMS60-4861	0.688	0.625	0.051	0.051	0.094	0.016	0.047	0.047	0.016	0.016	90. 00
AND10135-0501	0.625	0.563	0.050	0.050	0.075	0.050	0.075	0.075	0.010	0.010	90. 00
TMS60-5025	0.875	1.000	0.062	0.062	0.094	0.062	0.094	0.094	0.016	0.016	90. 00
TMS60-5263	1.125	0.960	0.090	0.100	0.094	0.031	0.125	0.115	0.031	0.031	90. 00
TMS60-5532	1.250	0.800	0.075	0.150	0.062	0.062	0.062	0.094	0.032	0.032	90. 00
TMS60-5733	0.750	1.250	0.064	0.064	0.120	0.016	0.120	0.090	0.016	0.016	90. 00
TMS60-6006	0.500	0.438	0.040	0.040	0.062	0.040	0.032	0.062	0.016	0.016	90. 00
AND10135-0601	0.750	0.563	0.050	0.050	0.075	0.050	0.075	0.075	0.010	0.010	90. 00
TMS60-6016	0.875	0.688	0.062	0.062	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
AND10135-0602	0.813	0.625	0.050	0.050	0.075	0.050	0.075	0.075	0.010	0.010	90. 00
TMS60-6048	0.938	0.375	0.050	0.050	0.050	0.040	0.075	0.075	0.015	0.015	90. 00
TMS60-6180	0.750	0.563	0.040	0.040	0.063	0.016	0.031	0.063	0.016	0.016	90. 00
TMS60-624	1.000	1.000	0.090	0.090	0.100	0.010	0.100	0.120	0.010	0.010	90. 00
TMS60-636	1.750	1.500	0.188	0.188	0.188	0.016	0.188	0.188	0.016	0.016	90. 00
TMS60-6481	1.000	1.850	0.063	0.050	0.125	0.016	0.125	0.125	0.016	0.016	90. 00
TMS60-649	1.250	0.950	0.080	0.125	0.125	0.016	0.125	0.125	0.016	0.016	90. 00
TMS60-6516	1.100	1.500	0.070	0.070	0.125	0.016	0.125	0.070	0.016	0.016	90. 00
TMS60-6525	0.750	0.531	0.051	0.051	0.062	0.016	0.062	0.062	0.016	0.016	90. 00
TMS60-6728	1.050	1.060	0.160	0.100	0.125	0.016	0.125	0.110	0.016	0.016	90. 00
TMS60-6768	1.100	1.250	0.070	0.070	0.040	0.062	0.062	0.070	0.031	0.031	90. 00
TMS60-70092	0.984	0.984	0.098	0.098	0.098	0.012	0.118	0.118	0.012	0.012	90. 00
AND10135-0701	0.875	0.625	0.050	0.050	0.075	0.050	0.075	0.075	0.010	0.010	90. 00
TMS60-70189	0.984	0.984	0.098	0.098	0.118	0.024	0.118	0.118	0.024	0.024	90. 00
TMS60-70215	0.984	0.709	0.063	0.063	0.063	0.016	0.063	0.098	0.016	0.016	90. 00
TMS60-70228	1.260	0.984	0.098	0.098	0.098	0.024	0.098	0.148	0.024	0.024	90. 00
TMS60-70252	1.260	0.984	0.098	0.098	0.098	0.024	0.024	0.148	0.024	0.024	90. 00
TMS60-70354	1.575	0.984	0.126	0.126	0.126	0.031	0.126	0.177	0.031	0.031	90. 00
TMS60-7047	0.688	0.688	0.040	0.040	0.060	0.030	0.060	0.060	0.016	0.016	90. 00
TMS60-70650	1.000	0.625	0.070	0.070	0.125	0.035	0.070	0.078	0.015	0.035	90. 00
TMS60-70671	1.000	0.875	0.062	0.062	0.094	0.016	0.125	0.078	0.016	0.016	90. 00
TMS60-70748	0.750	0.750	0.084	0.084	0.150	0.064	0.064	0.094	0.016	0.016	90. 00
TMS60-708	0.688	0.750	0.060	0.060	0.060	0.030	0.060	0.060	0.010	0.030	90. 00
TMS60-730	1.375	1.250	0.125	0.125	0.125	0.125	0.125	0.156	0.010	0.010	90. 00
TMS60-7302	0.813	0.813	0.051	0.051	0.063	0.016	0.063	0.063	0.016	0.016	90. 00
TMS60-7379	0.650	0.600	0.045	0.045	0.060	0.010	0.060	0.060	0.010	0.010	90. 00
TMS60-743	0.938	0.875	0.064	0.064	0.094	0.016	0.094	0.094	0.045	0.045	90. 00
TMS60-7432	0.750	1.350	0.050	0.050	0.060	0.016	0.060	0.050	0.016	0.016	90. 00
TMS60-7663	0.750	0.750	0.050	0.062	0.094	0.031	0.094	0.078	0.031	0.031	90. 00
TMS60-7816	0.800	1.200	0.078	0.078	0.100	0.031	0.100	0.100	0.031	0.031	90. 00
TMS60-786	0.875	0.625	0.051	0.051	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-801	1.125	0.750	0.062	0.062	0.125	0.016	0.109	0.109	0.016	0.016	90. 00
TMS60-8290	1.500	1.170	0.300	0.125	0.125	0.031	0.125	0.300	0.031	0.031	90. 00
TMS60-8367	1.000	1.000	0.070	0.125	0.130	0.016	0.130	0.088	0.016	0.016	90. 00
TMS60-8532	1.250	1.000	0.100	0.080	0.125	0.016	0.125	0.125	0.016	0.016	90. 00
TMS60-867	1.000	0.750	0.082	0.082	0.109	0.016	0.109	0.109	0.016	0.016	90. 00
TMS60-868	1.000	0.750	0.051	0.051	0.094	0.016	0.094	0.094	0.016	0.016	90. 00
TMS60-8684	1.125	1.000	0.072	0.062	0.125	0.062	0.109	0.109	0.016	0.016	90. 00
TMS60-8685	0.875	0.812	0.051	0.051	0.094	0.094	0.094	0.094	0.016	0.016	90. 00
TMS60-9143	1.000	1.000	0.094	0.094	0.125	0.016	0.125	0.068	0.016	0.016	90. 00
TMS60-9144	0.625	0.860	0.050	0.050	0.090	0.016	0.090	0.080	0.016	0.016	90. 00
TMS60-9145	1.270	0.500	0.040	0.040	0.060	0.016	0.060	0.060	0.016	0.016	90. 00
TMS60-9458	1.000	0.750	0.063	0.063	0.063	0.016	0.063	0.094	0.016	0.016	90. 00
TMS60-9493	1.200	1.000	0.080	0.130	0.090	0.031	0.125	0.078	0.031	0.031	90. 00
TMS60-9498	0.750	0.750	0.050	0.050	0.075	0.010	0.075	0.075	0.010	0.010	90. 00
TMS60-9505	0.630	0.630	0.047	0.047	0.047	0.012	0.047	0.069	0.047	0.012	90. 00
TMS60-9554	0.875	0.687	0.050	0.050	0.062	0.010	0.125	0.078	0.010	0.010	90. 00
TMS60-9701	1.000	1.130	0.062	0.062	0.078	0.016	0.078	0.078	0.016	0.016	90. 00

Part Number	A	B	T1	T2	R	R1	R2	R3	R4	R5	Deg.
Clear Filter
AND10135-1001	25.4	17.4752	1.27	1.27	1.905	1.27	1.905	1.905	0.254	0.254	90. 00
AND10135-1002	25.4	19.05	1.6002	1.6002	2.413	1.6002	2.413	2.413	0.254	0.254	90. 00
AND10135-1003	25.4	19.05	1.9812	1.9812	2.9718	1.9812	2.9718	2.9718	0.254	0.254	90. 00
AND10135-1004	25.4	22.225	1.9812	1.9812	2.9718	1.9812	2.9718	2.9718	0.254	0.254	90. 00
AND10135-1005	25.4	25.4	1.9812	1.9812	2.9718	1.9812	2.9718	2.9718	0.254	0.254	90. 00
TMS60-10057	22.86	23.876	1.651	1.651	2.286	0.4064	2.286	2.286	0.4064	0.4064	90. 00
TMS60-10111	19.05	15.875	1.2954	1.2954	3.175	0.4064	1.5748	1.5748	0.4064	0.4064	90. 00
TMS60-10128	18.0086	14.986	1.6002	1.6002	1.5748	0.4064	1.9812	1.9812	0.4064	0.4064	90. 00
TMS60-10257	25.4	22.225	1.6002	1.6002	2.413	0.254	2.413	2.413	0.254	0.254	90. 00
TMS60-10286	25.4	26.162	2.54	4.064	3.048	0.4064	3.048	2.54	0.4064	0.4064	90. 00
TMS60-10356	25.4	19.05	1.27	1.27	3.175	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-10489	44.45	25.4	2.032	2.54	3.9624	2.54	3.9624	3.9624	0.254	0.254	90. 00
TMS60-10577	31.75	22.225	4.3688	3.175	3.175	0.8128	3.175	4.3688	0.8128	0.8128	90. 00
TMS60-10705	22.225	20.6502	1.6002	1.6002	3.175	1.6002	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-10759	22.225	19.05	1.27	1.27	1.5748	0.4064	3.175	1.9812	0.4064	0.4064	90. 00
TMS60-11068	25.4	38.1	1.27	1.27	1.27	0.4064	2.413	2.413	2.54	0.4064	90. 00
TMS60-11092	28.321	16.5862	1.0414	1.143	3.175	0.5588	2.9972	2.3622	0.4064	0.5588	90. 00
TMS60-11113	20.32	22.86	1.27	1.27	2.159	0.4064	2.159	2.159	0.4064	0.4064	90. 00
TMS60-11142	38.1	25.4	2.54	1.778	3.81	0.4064	3.81	3.81	0.4064	0.4064	90. 00
TMS60-11175	25.4	25.4	1.5748	1.5748	2.3876	0.4064	3.175	1.9812	0.4064	0.4064	90. 00
TMS60-11416	25.4	31.75	1.6002	1.6002	2.3622	0.7874	2.3622	2.3622	0.7874	0.7874	90. 00
TMS60-11481	22.225	25.4	1.9812	1.9812	2.9718	1.9812	2.9718	2.9718	0.254	0.254	90. 00
TMS60-11760	38.1	25.4	1.778	1.778	4.7498	0.4064	4.7498	4.7498	0.4064	0.4064	90. 00
TMS60-11778	20.574	22.86	1.016	1.016	1.905	0.4064	1.905	1.905	0.4064	0.4064	90. 00
TMS60-11789	15.875	21.082	3.3274	2.6924	3.175	0.4064	2.286	3.175	0.4064	0.4064	90. 00
TMS60-11826	38.1	29.718	2.032	3.048	3.048	3.048	3.048	3.048	0.4064	0.4064	90. 00
TMS60-11827	25.4	22.225	1.7272	1.7272	3.175	0.762	3.9624	2.1844	0.762	0.762	90. 00
AND10135-1201	31.75	22.225	1.9812	1.9812	2.9718	1.9812	2.9718	2.9718	0.254	0.254	90. 00
TMS60-12129	25.4	20.32	1.5748	1.5748	1.5748	0.4064	1.5748	2.286	0.4064	0.4064	90. 00
TMS60-12247	25.908	38.1	2.3876	2.794	2.286	0.4064	2.286	2.9718	0.4064	0.4064	90. 00
TMS60-12326	31.75	26.924	1.9812	1.9812	2.9718	0.4064	2.9718	2.9718	0.4064	0.4064	90. 00
TMS60-12353	14.2748	31.75	2.5908	2.3876	2.3876	2.3876	2.3876	2.3876	0.8128	0.8128	90. 00
TMS60-12392	20.32	20.32	1.27	1.27	1.5748	0.4064	1.5748	1.524	0.4064	0.4064	90. 00
TMS60-12470	22.7838	12.7	1.8288	1.8288	2.286	0.4064	2.286	2.4638	0.4064	0.4064	90. 00
TMS60-12579	12.7	25.4	1.27	1.27	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-12661	22.225	15.875	1.5748	1.5748	1.9812	0.4064	1.5748	1.5748	0.4064	0.4064	90. 00
TMS60-12817	19.05	19.05	2.0828	2.0828	2.3876	0.4064	1.5748	2.3876	0.4064	0.4064	90. 00
TMS60-12941	12.7	19.05	1.016	1.016	1.5748	0.4064	1.5748	1.5748	0.4064	0.4064	90. 00
TMS60-12949	19.05	19.05	1.016	1.5748	2.286	0.4064	2.286	1.5748	0.4064	0.4064	90. 00
TMS60-13283	19.05	25.4	1.27	1.27	3.175	0.4064	3.175	1.5748	0.4064	0.4064	90. 00
TMS60-133	12.7	20.6248	1.2954	1.2954	1.5748	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-13359	18.0086	15.0114	1.6256	1.6256	2.2098	0.3048	1.7526	1.7526	0.3048	0.3048	90. 00
TMS60-13494	27.94	19.05	1.4732	2.286	1.524	0.4064	1.524	2.3876	0.4064	0.4064	90. 00
TMS60-13736	15.24	46.99	1.524	1.524	1.778	0.508	0.508	1.524	0.508	0.508	90. 00
TMS60-13969	27.94	25.654	1.778	3.048	3.175	0.4064	3.175	1.778	0.4064	0.4064	90. 00
AND10135-1401	38.1	22.225	1.9812	1.9812	2.9718	1.9812	2.9718	2.9718	0.254	0.254	90. 00
TMS60-14469	17.526	15.875	1.27	1.27	1.778	0.4064	1.27	1.778	0.4064	0.4064	90. 00
TMS60-1447	25.4	22.225	1.9812	1.9812	3.175	0.254	3.9624	2.1844	0.254	0.254	90. 00
TMS60-14499	25.4	19.812	2.5908	2.5908	1.524	0.4064	1.524	3.048	0.4064	0.4064	90. 00
TMS60-14621	32.004	19.9898	2.0066	2.0066	2.0066	0.508	2.0066	2.9972	0.508	0.508	90. 00
TMS60-14745	35.052	28.448	3.556	3.556	3.9624	2.286	3.9624	3.9624	0.7874	0.7874	90. 00
TMS60-14794	19.9898	16.002	1.1938	1.1938	1.1938	0.3048	1.1938	1.7526	0.3048	0.3048	90. 00
TMS60-14895	22.225	12.7	1.5748	1.5748	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-14930	33.3248	19.05	2.3876	2.3876	3.5814	0.7874	3.5814	3.5814	0.7874	0.7874	90. 00
TMS60-15003	50.8	29.21	2.54	5.08	3.175	0.4064	3.175	3.175	0.4064	0.4064	90. 00
AND10135-1501	41.275	22.225	2.3876	2.3876	2.9718	2.3876	2.9718	2.9718	0.254	0.254	90. 00
TMS60-15025	15.0622	15.0622	1.016	1.016	1.1938	0.4064	1.1938	1.1938	0.4064	0.4064	90. 00
TMS60-15041	25.4	40.64	1.6002	1.6002	3.302	0.4064	2.286	1.143	0.4064	0.4064	90. 00
TMS60-15102	50.0126	32.004	3.2004	3.2004	3.2004	0.8128	3.2004	4.4958	0.8128	0.8128	90. 00
TMS60-15103	62.992	40.005	3.9878	3.9878	3.9878	0.9906	3.9878	5.9944	0.9906	0.9906	90. 00
TMS60-15149	31.75	31.75	1.9812	1.9812	2.9718	0.9906	2.9718	3.81	0.8128	0.9906	90. 00
TMS60-1521	22.225	19.05	1.5748	1.5748	2.3876	0.7874	2.3876	2.3876	0.254	0.7874	90. 00
TMS60-15213	38.1	30.1752	1.9812	1.9812	2.9718	0.9906	2.9718	3.81	0.8128	0.9906	90. 00
TMS60-15229	19.05	22.098	1.778	1.778	1.778	0.254	0.7874	1.778	0.254	0.254	90. 00
TMS60-15338	22.225	14.2748	1.524	1.524	1.5748	0.7874	2.3876	2.3876	0.7874	0.7874	90. 00
TMS60-15381	27.94	37.338	1.778	2.794	3.175	0.4064	3.175	1.778	0.4064	0.4064	90. 00
TMS60-15432	27.94	30.48	1.778	2.794	3.175	0.4064	3.175	1.778	0.4064	0.4064	90. 00
TMS60-15580	19.9898	16.002	1.6002	1.6002	1.6002	0.7874	1.6002	2.5146	0.7874	0.7874	90. 00
TMS60-15581	50.0126	32.004	2.9972	2.9972	2.9972	0.762	2.9972	4.4958	0.762	0.762	90. 00
TMS60-15649	19.05	13.462	1.016	1.016	1.524	0.381	3.048	1.016	0.381	0.381	90. 00
TMS60-15877	25.4	21.336	2.032	2.159	3.175	0.7874	3.175	3.175	0.7874	0.7874	90. 00
TMS60-15879	25.4	27.178	1.27	1.27	1.524	0.4064	1.524	1.6002	0.4064	0.4064	90. 00
TMS60-15971	28.575	44.45	2.54	4.445	3.9624	3.9624	3.048	3.048	0.7874	0.7874	90. 00
AND10135-1601	44.45	28.575	2.3876	2.3876	2.9718	2.3876	2.9718	2.9718	0.254	0.254	90. 00
AND10135-1602	44.45	31.75	2.7686	2.7686	3.4544	2.7686	3.4544	3.4544	0.254	0.254	90. 00
TMS60-16026	30.6832	15.748	1.524	2.0066	1.651	0.635	3.175	2.1844	0.635	0.635	90. 00
AND10135-1603	44.45	31.75	3.175	3.175	3.9624	3.175	3.9624	3.9624	0.254	0.254	90. 00
TMS60-1613	38.1	19.05	1.6256	2.54	3.175	2.54	3.175	3.175	0.7874	0.7874	90. 00
TMS60-1615	14.224	19.05	1.2954	1.2954	1.5748	0.7874	1.5748	1.5748	0.7874	0.7874	90. 00
TMS60-16273	16.9926	16.002	0.9906	0.9906	2.0066	0.4064	0.9906	1.6002	0.4064	0.4064	90. 00
TMS60-16334	21.9964	16.9926	1.8034	1.8034	2.9972	0.4064	2.0066	2.2606	0.4064	0.4064	90. 00
TMS60-16475	17.4752	19.05	1.8034	1.8034	2.3876	0.4064	1.6002	2.3876	0.4064	0.4064	90. 00
TMS60-16614	28.575	24.892	2.54	3.175	3.175	0.7874	3.175	2.921	0.7874	0.7874	90. 00
TMS60-16660	19.05	24.13	3.81	2.3622	3.175	1.5748	3.175	3.9624	0.7874	0.7874	90. 00
TMS60-16694	27.7876	15.875	1.9812	1.9812	3.175	0.4064	3.175	2.9718	0.4064	0.4064	90. 00
TMS60-16760	19.05	22.86	3.556	2.0574	3.175	1.5748	3.175	3.556	0.8128	0.4064	90. 00
TMS60-16763	27.94	29.464	1.778	3.048	3.175	0.4064	3.175	1.778	0.4064	0.4064	90. 00
TMS60-16788	25.4	23.6474	3.175	3.81	3.175	0.7874	3.175	3.556	0.7874	0.7874	90. 00
TMS60-16975	30.48	25.4	1.143	1.143	1.524	0.254	1.524	1.524	0.254	0.254	90. 00
TMS60-16996	25.4	25.4	1.778	1.778	2.9718	0.4064	2.9718	2.9718	0.4064	0.4064	90. 00
TMS60-17044	30.48	27.94	1.778	2.794	3.175	0.7874	3.175	2.54	0.7874	0.7874	90. 00
TMS60-17166	15.875	20.574	1.27	1.27	2.286	0.4064	2.286	2.032	0.4064	0.4064	90. 00
TMS60-17327	10.16	46.99	1.524	1.524	1.778	0.508	0.508	1.524	0.508	0.508	90. 00
TMS60-17387	25.4	20.828	1.9812	1.9812	3.175	0.7874	3.175	2.1844	0.7874	0.7874	90. 00
TMS60-17698	34.925	38.1	3.175	3.175	3.175	0.4064	4.7752	4.7752	0.4064	0.4064	90. 00
TMS60-17841	24.9936	19.9898	2.0066	2.0066	2.0066	0.508	2.0066	2.9972	0.508	0.508	90. 00
TMS60-18482	22.225	19.05	1.5748	1.5748	1.5748	0.4064	3.175	1.9812	0.4064	0.4064	90. 00
TMS60-18502	31.75	25.4	2.286	4.064	3.175	0.7874	3.175	2.54	0.7874	0.7874	90. 00
TMS60-1877	25.4	25.4	1.524	2.032	3.175	0.4064	3.175	1.5748	0.4064	0.4064	90. 00
TMS60-19090	27.94	37.338	1.778	3.048	3.175	0.4064	3.175	1.778	0.4064	0.4064	90. 00
TMS60-19185	19.05	19.05	1.27	1.27	1.905	0.254	1.905	3.175	0.254	0.254	90. 00
TMS60-1931	31.75	22.86	1.905	3.556	1.5748	1.5748	1.5748	2.3876	0.7874	0.7874	90. 00
TMS60-1954	38.1	31.75	2.3876	4.318	3.175	0.4064	2.3876	1.9812	0.4064	0.4064	90. 00
TMS60-19556	25.4	20.574	2.286	2.286	2.3876	0.4064	2.3876	1.9812	0.4064	0.4064	90. 00
TMS60-19794	28.575	20.6502	2.3876	2.3876	2.9718	2.3876	2.9718	2.9718	0.4064	0.4064	90. 00
TMS60-2004	23.114	57.15	1.6002	1.6002	3.175	0.4064	6.35	2.032	0.4064	0.4064	90. 00
TMS60-20237	28.575	27.432	2.54	3.175	3.175	0.7874	3.175	2.921	0.7874	0.7874	90. 00
TMS60-20259	38.1	22.225	1.778	2.54	3.175	0.7874	3.175	3.175	0.7874	0.7874	90. 00
TMS60-20292	16.002	13.9954	0.9906	0.9906	2.0066	0.3048	0.9906	1.6002	0.3048	0.3048	90. 00
TMS60-20398	12.7	17.78	1.143	1.143	1.524	0.4064	1.524	1.524	0.4064	0.4064	90. 00
TMS60-2046	25.4	22.352	1.5748	1.5748	2.3876	0.7874	3.175	1.9812	0.762	0.7874	90. 00
TMS60-2089	19.0246	31.75	1.778	1.778	2.3876	0.4064	1.016	2.413	0.4064	0.4064	90. 00
TMS60-2115	12.7	22.225	2.286	2.286	1.524	0.381	2.54	2.54	0.381	0.381	90. 00
TMS60-21367	25.4	22.86	1.4732	2.8448	1.5748	1.5748	1.5748	1.905	0.7874	0.7874	90. 00
TMS60-21412	31.75	25.4	2.3876	2.3876	2.3876	2.3876	3.175	3.175	2.3876	2.3876	90. 00
TMS60-21991	25.4	27.94	2.794	3.175	3.175	0.7874	3.175	3.556	0.7874	0.7874	90. 00
TMS60-22157	82.55	101.6	6.35	4.7752	6.35	1.016	6.35	7.112	1.016	1.016	90. 00
TMS60-22624	20.32	25.4	1.016	1.016	0.508	0.4064	0.8128	1.6002	0.4064	0.4064	90. 00
TMS60-22905	23.622	19.05	1.524	3.048	1.524	0.7874	2.159	2.159	0.7874	0.7874	90. 00
TMS60-22925	35.052	31.75	5.588	3.81	4.572	0.7874	4.572	5.842	0.7874	0.7874	90. 00
TMS60-2294	10.287	21.336	1.5748	1.5748	1.905	0.7874	1.905	1.905	0.4064	0.7874	90. 00
TMS60-23356	44.45	27.94	2.794	3.556	3.4544	3.556	3.4544	3.4544	0.4064	0.4064	90. 00
TMS60-23472	30.1498	23.7998	2.032	1.778	3.175	0.254	3.175	2.7686	0.254	0.254	90. 00
TMS60-23683	20.32	30.48	1.9812	1.9812	2.54	0.7874	2.54	2.54	0.7874	0.7874	90. 00
TMS60-23976	30.1752	20.6502	2.1082	2.1082	1.6002	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-24363	47.625	44.45	6.35	4.7498	3.175	0.4064	5.5626	5.5626	0.4064	0.4064	90. 00
TMS60-24551	17.4752	15.875	1.27	1.27	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-2459	31.75	40.64	3.81	6.35	3.048	0.762	3.048	3.937	0.762	0.762	90. 00
TMS60-24591	31.75	22.352	3.175	3.175	3.175	0.762	3.175	2.9718	0.762	0.762	90. 00
TMS60-24785	35.052	26.67	3.175	3.175	3.048	0.4064	3.048	3.8862	0.4064	0.4064	90. 00
TMS60-2481	25.4	23.8252	1.6256	1.6256	1.6256	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-2497	25.4	25.4	2.3622	2.3622	3.175	1.1684	3.175	3.175	0.7874	1.1684	90. 00
TMS60-25209	25.4	28.575	1.27	1.27	3.175	0.4064	2.413	2.413	0.4064	0.4064	90. 00
TMS60-25283	30.1752	28.575	4.7752	2.3622	3.175	1.1938	3.175	3.9624	0.8128	1.1938	90. 00
TMS60-2562	22.86	25.4	1.651	1.651	2.286	0.4064	2.286	2.286	0.4064	0.4064	90. 00
TMS60-25621	17.4752	19.05	2.032	2.032	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-2565	31.75	31.75	1.6256	1.6256	2.286	2.286	2.286	2.286	0.7874	0.7874	90. 00
TMS60-25684	31.75	31.75	2.3876	2.3876	2.9718	2.3876	2.9718	2.9718	0.254	0.254	90. 00
TMS60-2581	38.1	28.575	2.54	2.54	3.175	1.27	3.175	3.175	0.762	1.27	90. 00
TMS60-25855	22.225	14.3002	1.5748	1.5748	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-26088	25.4	9.652	1.27	1.27	0.8128	0.635	0.8128	1.524	0.8128	0.635	90. 00
TMS60-26287	25.4	22.606	3.175	3.81	3.81	0.7874	3.175	3.556	0.7874	0.7874	90. 00
TMS60-26306	24.9936	26.0096	2.9972	2.9972	2.9972	0.4064	2.9972	2.9972	0.4064	0.4064	90. 00
TMS60-2653	26.9748	19.05	2.032	2.032	3.175	0.7874	3.175	2.9718	0.7874	0.7874	90. 00
TMS60-26833	29.21	21.59	1.524	1.905	2.286	0.7874	2.286	2.794	0.7874	0.7874	90. 00
TMS60-26975	34.925	19.05	1.27	1.27	2.3622	0.254	2.3622	2.3622	0.254	0.254	90. 00
TMS60-27064	31.75	31.75	2.3876	2.3876	3.175	0.4064	3.5814	3.5814	0.4064	0.4064	90. 00
TMS60-27534	19.05	19.05	1.016	1.016	2.286	0.4064	2.286	1.5748	0.4064	0.4064	90. 00
TMS60-27645	15.875	25.4	1.2954	1.2954	1.905	1.2954	1.905	1.905	0.254	0.254	90. 00
TMS60-2803	25.4	25.4	1.8034	1.8034	3.175	0.4064	2.794	2.794	0.4064	0.4064	90. 00
TMS60-28635	17.4752	19.05	2.032	2.032	2.286	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-28673	63.5	66.04	2.286	1.905	3.175	0.4064	3.175	3.9624	0.4064	0.4064	90. 00
TMS60-29316	25.4	22.225	1.9812	1.9812	3.048	0.4064	4.064	2.286	0.4064	0.4064	90. 00
TMS60-29353	25.4	25.4	2.54	2.54	2.54	0.7874	2.54	3.048	0.7874	0.7874	90. 00
TMS60-29441	25.4	31.75	1.9812	1.9812	2.286	0.7874	3.048	3.048	0.7874	0.7874	90. 00
TMS60-31007	19.05	19.05	1.524	1.524	1.524	0.381	2.3876	2.3876	0.381	0.381	90. 00
TMS60-3168	19.05	25.4	1.9812	1.9812	3.175	0.762	3.175	3.175	0.762	0.762	90. 00
TMS60-31724	17.145	15.875	1.2954	1.2954	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-31868	25.4	25.4	1.778	5.08	2.9718	2.9718	2.9718	2.9718	0.7874	0.7874	90. 00
TMS60-31985	38.1	29.718	2.032	2.032	3.048	2.032	3.048	3.048	0.7874	0.7874	90. 00
TMS60-3200	22.86	25.4	1.27	1.27	2.286	0.4064	1.905	1.905	0.4064	0.4064	90. 00
TMS60-32863	20.6248	12.7	1.3208	1.3208	1.5748	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-33043	25.4	17.4752	1.6256	1.6256	1.6256	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-33693	39.37	51.816	3.048	2.794	4.7752	0.7874	4.7752	4.7752	0.7874	0.7874	90. 00
TMS60-33737	31.75	41.275	2.54	1.5748	3.175	0.762	3.175	2.3622	0.762	0.762	90. 00
TMS60-338	19.05	19.05	1.6002	1.6002	2.413	1.6002	2.413	2.413	0.254	0.254	90. 00
TMS60-33913	31.75	22.225	1.9812	1.9812	2.9718	1.9812	2.9718	2.9718	0.4064	0.4064	90. 00
TMS60-34161	24.9936	24.9936	2.0066	2.0066	2.0066	0.4064	2.0066	2.4892	0.4064	0.4064	90. 00
TMS60-34241	18.0086	15.0114	1.6256	1.6256	2.2098	0.4064	1.7526	1.7526	0.4064	0.4064	90. 00
TMS60-34338	24.9936	19.9898	2.4892	2.0066	2.4892	0.4064	2.4892	1.7526	0.4064	0.4064	90. 00
TMS60-34428	25.4	22.225	1.5748	1.5748	2.3876	0.4064	2.3876	1.9812	0.4064	0.4064	90. 00
TMS60-34429	25.4	22.352	1.5748	1.5748	2.3876	0.7874	3.175	1.9812	1.016	0.7874	90. 00
TMS60-34499	18.0086	16.002	0.9906	0.9906	2.0066	0.2032	0.9906	1.6002	0.2032	0.2032	90. 00
TMS60-34509	32.004	19.9898	2.0066	2.0066	2.0066	0.4826	2.0066	2.9972	0.4826	0.4826	90. 00
TMS60-34518	25.4	23.8252	1.6256	1.6256	1.6256	0.254	1.6256	2.3876	0.254	0.254	90. 00
TMS60-34569	16.002	16.002	1.6002	1.6002	1.6002	0.4064	1.6002	2.4892	0.4064	0.4064	90. 00
TMS60-34585	20.2438	17.78	1.5748	1.5748	1.9812	0.4064	1.9812	1.9812	0.4064	0.4064	90. 00
TMS60-34691	25.4	28.575	2.0066	2.0066	2.9972	0.4064	2.9972	3.5052	0.4064	0.4064	90. 00
TMS60-34788	20.32	20.1422	1.6002	1.6002	2.413	0.254	2.9718	2.9718	1.6002	0.254	90. 00
TMS60-34811	25.4	29.9974	1.6002	1.6002	2.794	0.4064	2.794	2.8956	0.4064	0.4064	90. 00
TMS60-34814	25.4	29.9974	0.9906	0.9906	2.0066	0.4064	2.0066	2.0574	0.4064	0.4064	90. 00
TMS60-35119	25.4	29.9974	2.4892	2.4892	2.4892	0.4064	2.9972	4.0132	0.4064	0.4064	90. 00
TMS60-35502	19.05	31.75	1.6002	1.6002	2.286	0.4064	3.048	2.286	0.4064	0.4064	90. 00
TMS60-35523	25.4	19.05	1.6002	1.6002	2.413	1.6002	2.413	2.413	0.4064	0.4064	90. 00
TMS60-3553	43.18	30.48	3.302	3.302	4.7752	0.8128	2.3876	3.9624	0.8128	0.8128	90. 00
TMS60-35635	19.05	19.05	1.6002	1.6002	2.413	0.254	2.413	2.413	0.254	0.254	90. 00
TMS60-35897	32.1564	16.6624	2.159	2.159	3.175	0.4064	3.175	3.175	0.4064	0.4064	90. 00
TMS60-35909	44.45	25.4	2.3622	2.3622	3.175	0.4064	19.05	6.35	0.4064	0.4064	90. 00
TMS60-36052	12.7	15.875	1.016	1.016	1.524	1.016	1.524	1.524	0.381	0.381	90. 00
TMS60-36080	22.86	22.86	1.778	1.778	3.175	0.7874	3.175	5.5626	0.7874	0.7874	90. 00
TMS60-36888	25.4	20.828	1.6002	1.6002	2.032	0.508	2.032	2.54	0.508	0.508	90. 00
TMS60-3700	27.0002	23.876	2.3876	2.3876	2.3876	0.4064	2.3876	4.7752	1.6002	0.4064	90. 00
TMS60-3843	57.15	31.75	2.54	3.175	4.826	3.175	4.826	4.826	0.4064	0.4064	90. 00
TMS60-3855	25.4	19.05	1.2954	1.5748	2.3876	0.7874	1.9812	1.9812	0.7874	0.7874	90. 00
TMS60-3856	33.3248	31.75	1.778	2.159	3.175	1.5748	2.3876	2.3876	0.7874	0.7874	90. 00
TMS60-3857	22.352	28.575	1.5748	1.5748	1.016	0.7874	1.5748	1.5748	0.7874	0.7874	90. 00
TMS60-3886	38.1	25.4	2.032	2.54	3.9624	2.54	3.9624	3.9624	0.7874	0.7874	90. 00
TMS60-3960	34.925	25.4	3.175	3.175	3.9624	3.175	3.9624	3.9624	0.4064	0.4064	90. 00
TMS60-3975	25.4	19.05	1.27	1.27	1.5748	0.254	1.5748	1.905	0.254	0.254	90. 00
AND10135-0401	12.7	12.7	1.016	1.016	1.524	1.016	1.524	1.524	0.254	0.254	90. 00
AND10135-0402	12.7	15.875	1.016	1.016	1.524	1.016	1.524	1.524	0.254	0.254	90. 00
TMS60-4060	35.052	19.05	1.6256	2.032	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-414	26.5938	29.3624	3.175	2.3876	3.175	1.1938	0.4064	3.175	0.4064	1.1938	90. 00
TMS60-4269	15.875	25.4	1.5748	1.5748	1.905	0.4064	1.905	1.905	0.4064	0.4064	90. 00
TMS60-4407	22.352	22.352	1.524	1.524	3.048	0.4064	3.048	2.3876	0.4064	0.4064	90. 00
TMS60-4499	53.848	31.75	1.5748	1.5748	3.048	0.7874	3.048	3.048	0.7874	0.7874	90. 00
TMS60-4695	24.13	52.07	2.032	1.778	1.1938	0.7874	2.3876	2.3876	0.7874	0.7874	90. 00
TMS60-4716	20.2438	20.2438	1.5748	1.5748	1.9812	0.4064	1.9812	1.9812	0.4064	0.4064	90. 00
TMS60-4739	19.05	12.7	1.016	1.016	1.5748	0.4064	0.8128	1.5748	0.4064	0.4064	90. 00
TMS60-4758	22.352	19.05	1.6002	1.6002	2.032	0.7874	2.032	2.032	0.7874	0.7874	90. 00
TMS60-4861	17.4752	15.875	1.2954	1.2954	2.3876	0.4064	1.1938	1.1938	0.4064	0.4064	90. 00
AND10135-0501	15.875	14.3002	1.27	1.27	1.905	1.27	1.905	1.905	0.254	0.254	90. 00
TMS60-5025	22.225	25.4	1.5748	1.5748	2.3876	1.5748	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-5263	28.575	24.384	2.286	2.54	2.3876	0.7874	3.175	2.921	0.7874	0.7874	90. 00
TMS60-5532	31.75	20.32	1.905	3.81	1.5748	1.5748	1.5748	2.3876	0.8128	0.8128	90. 00
TMS60-5733	19.05	31.75	1.6256	1.6256	3.048	0.4064	3.048	2.286	0.4064	0.4064	90. 00
TMS60-6006	12.7	11.1252	1.016	1.016	1.5748	1.016	0.8128	1.5748	0.4064	0.4064	90. 00
AND10135-0601	19.05	14.3002	1.27	1.27	1.905	1.27	1.905	1.905	0.254	0.254	90. 00
TMS60-6016	22.225	17.4752	1.5748	1.5748	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
AND10135-0602	20.6502	15.875	1.27	1.27	1.905	1.27	1.905	1.905	0.254	0.254	90. 00
TMS60-6048	23.8252	9.525	1.27	1.27	1.27	1.016	1.905	1.905	0.381	0.381	90. 00
TMS60-6180	19.05	14.3002	1.016	1.016	1.6002	0.4064	0.7874	1.6002	0.4064	0.4064	90. 00
TMS60-624	25.4	25.4	2.286	2.286	2.54	0.254	2.54	3.048	0.254	0.254	90. 00
TMS60-636	44.45	38.1	4.7752	4.7752	4.7752	0.4064	4.7752	4.7752	0.4064	0.4064	90. 00
TMS60-6481	25.4	46.99	1.6002	1.27	3.175	0.4064	3.175	3.175	0.4064	0.4064	90. 00
TMS60-649	31.75	24.13	2.032	3.175	3.175	0.4064	3.175	3.175	0.4064	0.4064	90. 00
TMS60-6516	27.94	38.1	1.778	1.778	3.175	0.4064	3.175	1.778	0.4064	0.4064	90. 00
TMS60-6525	19.05	13.4874	1.2954	1.2954	1.5748	0.4064	1.5748	1.5748	0.4064	0.4064	90. 00
TMS60-6728	26.67	26.924	4.064	2.54	3.175	0.4064	3.175	2.794	0.4064	0.4064	90. 00
TMS60-6768	27.94	31.75	1.778	1.778	1.016	1.5748	1.5748	1.778	0.7874	0.7874	90. 00
TMS60-70092	24.9936	24.9936	2.4892	2.4892	2.4892	0.3048	2.9972	2.9972	0.3048	0.3048	90. 00
AND10135-0701	22.225	15.875	1.27	1.27	1.905	1.27	1.905	1.905	0.254	0.254	90. 00
TMS60-70189	24.9936	24.9936	2.4892	2.4892	2.9972	0.6096	2.9972	2.9972	0.6096	0.6096	90. 00
TMS60-70215	24.9936	18.0086	1.6002	1.6002	1.6002	0.4064	1.6002	2.4892	0.4064	0.4064	90. 00
TMS60-70228	32.004	24.9936	2.4892	2.4892	2.4892	0.6096	2.4892	3.7592	0.6096	0.6096	90. 00
TMS60-70252	32.004	24.9936	2.4892	2.4892	2.4892	0.6096	0.6096	3.7592	0.6096	0.6096	90. 00
TMS60-70354	40.005	24.9936	3.2004	3.2004	3.2004	0.7874	3.2004	4.4958	0.7874	0.7874	90. 00
TMS60-7047	17.4752	17.4752	1.016	1.016	1.524	0.762	1.524	1.524	0.4064	0.4064	90. 00
TMS60-70650	25.4	15.875	1.778	1.778	3.175	0.889	1.778	1.9812	0.381	0.889	90. 00
TMS60-70671	25.4	22.225	1.5748	1.5748	2.3876	0.4064	3.175	1.9812	0.4064	0.4064	90. 00
TMS60-70748	19.05	19.05	2.1336	2.1336	3.81	1.6256	1.6256	2.3876	0.4064	0.4064	90. 00
TMS60-708	17.4752	19.05	1.524	1.524	1.524	0.762	1.524	1.524	0.254	0.762	90. 00
TMS60-730	34.925	31.75	3.175	3.175	3.175	3.175	3.175	3.9624	0.254	0.254	90. 00
TMS60-7302	20.6502	20.6502	1.2954	1.2954	1.6002	0.4064	1.6002	1.6002	0.4064	0.4064	90. 00
TMS60-7379	16.51	15.24	1.143	1.143	1.524	0.254	1.524	1.524	0.254	0.254	90. 00
TMS60-743	23.8252	22.225	1.6256	1.6256	2.3876	0.4064	2.3876	2.3876	1.143	1.143	90. 00
TMS60-7432	19.05	34.29	1.27	1.27	1.524	0.4064	1.524	1.27	0.4064	0.4064	90. 00
TMS60-7663	19.05	19.05	1.27	1.5748	2.3876	0.7874	2.3876	1.9812	0.7874	0.7874	90. 00
TMS60-7816	20.32	30.48	1.9812	1.9812	2.54	0.7874	2.54	2.54	0.7874	0.7874	90. 00
TMS60-786	22.225	15.875	1.2954	1.2954	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-801	28.575	19.05	1.5748	1.5748	3.175	0.4064	2.7686	2.7686	0.4064	0.4064	90. 00
TMS60-8290	38.1	29.718	7.62	3.175	3.175	0.7874	3.175	7.62	0.7874	0.7874	90. 00
TMS60-8367	25.4	25.4	1.778	3.175	3.302	0.4064	3.302	2.2352	0.4064	0.4064	90. 00
TMS60-8532	31.75	25.4	2.54	2.032	3.175	0.4064	3.175	3.175	0.4064	0.4064	90. 00
TMS60-867	25.4	19.05	2.0828	2.0828	2.7686	0.4064	2.7686	2.7686	0.4064	0.4064	90. 00
TMS60-868	25.4	19.05	1.2954	1.2954	2.3876	0.4064	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-8684	28.575	25.4	1.8288	1.5748	3.175	1.5748	2.7686	2.7686	0.4064	0.4064	90. 00
TMS60-8685	22.225	20.6248	1.2954	1.2954	2.3876	2.3876	2.3876	2.3876	0.4064	0.4064	90. 00
TMS60-9143	25.4	25.4	2.3876	2.3876	3.175	0.4064	3.175	1.7272	0.4064	0.4064	90. 00
TMS60-9144	15.875	21.844	1.27	1.27	2.286	0.4064	2.286	2.032	0.4064	0.4064	90. 00
TMS60-9145	32.258	12.7	1.016	1.016	1.524	0.4064	1.524	1.524	0.4064	0.4064	90. 00
TMS60-9458	25.4	19.05	1.6002	1.6002	1.6002	0.4064	1.6002	2.3876	0.4064	0.4064	90. 00
TMS60-9493	30.48	25.4	2.032	3.302	2.286	0.7874	3.175	1.9812	0.7874	0.7874	90. 00
TMS60-9498	19.05	19.05	1.27	1.27	1.905	0.254	1.905	1.905	0.254	0.254	90. 00
TMS60-9505	16.002	16.002	1.1938	1.1938	1.1938	0.3048	1.1938	1.7526	1.1938	0.3048	90. 00
TMS60-9554	22.225	17.4498	1.27	1.27	1.5748	0.254	3.175	1.9812	0.254	0.254	90. 00
TMS60-9701	25.4	28.702	1.5748	1.5748	1.9812	0.4064	1.9812	1.9812	0.4064	0.4064	90. 00

How to use our search tool for Aluminum Bulb Angle

The data table has some powerfull tools to help you search through Aluminum Bulb Angle. Using the sort function and filters, we provide a unique user experience taking the hastle out of finding extruded shapes to funnel down, not just to the best fit extrusion, but a profile that is either available from stock or an item that we are tooled for.

Services and processes for your Aluminum Bulb Angle

Aircraft Extrusion Company offers CNC Machining, Forming, Rolling and Shrinking of aerospace profiles. Our fast turn around times are days, not weeks. Custom tooling and expert team of fabricators and engineering prove a single source for material processing and handling.

New OEM Parts

Aerospace Extrusion technology has grown. Today we can extrude as little as 12ft within 5 weeks with your custom design. Our CAD team provide quotes within one day. Pricing is exceptionally competative. Our die charges start at $325.00 for a new die. Unlike soft alloys like 5052, 6061, Aerospace alloys have to be extruded on special machines. Mechanical properties have to be locked in during the heat treatment process, then we test material for dimentional tolerance, mechanical and chemical composition. All our aerospace profiles are supplied with full certification and qualified for all major specifications including AMS, QQA, WWT amd AMS specifications.

Expanded Product Range

Aluminum Bulb Angle

Description

How to use our search tool for Aluminum Bulb Angle

Services and processes for your Aluminum Bulb Angle

New OEM Parts
